Structural Design Coordination by Sigma Solutions

Introduction

When a reputed real estate developer initiated plans for a mixed-use commercial high-rise, the complexities of integrating architectural vision with structural feasibility became a roadblock. Initial design inconsistencies, misaligned load paths, and MEP (Mechanical, Electrical, and Plumbing) clashes threatened both the timeline and budget. Recognizing the need for seamless execution and technical accuracy, the developer engaged Sigma Solutions to lead the structural design coordination process using advanced BIM integration and structural analysis techniques.

This case study details how Sigma Solutions eliminated critical design conflicts, ensured safety compliance, and optimized structural materials to deliver a durable and cost-efficient high-rise solution.

Challenges Faced

1. Structural-Architectural Misalignment

The original blueprints revealed significant misalignments between architectural layout and structural load-bearing points. Columns clashed with window openings, and slab thicknesses were miscalculated, threatening the building’s stability and aesthetic.

2. MEP Clash Detection & Rework Risks

During design-stage reviews, Sigma detected multiple overlaps between HVAC ducts, plumbing lines, and structural beams, particularly in the service cores and ceiling zones—areas prone to costly rework if not resolved early.

3. Seismic and Load Compliance Needs

Located in Seismic Zone V, the project required advanced load-bearing analysis for earthquake and wind resilience. Without this, the building risked structural failure during extreme conditions.

4. Material Overuse and Cost Overruns

Poor load distribution and absence of optimized cross-sections led to excess use of concrete and steel, increasing costs by over 20% and potentially reducing project profitability.

5. Disrupted On-Site Execution

The absence of synchronized structural and MEP drawings created communication gaps among contractors and engineers, leading to delays, site-level confusion, and high error margins during fabrication and assembly.

Solution Provided by Sigma Solutions

Sigma Solutions adopted a BIM-powered, multi-disciplinary coordination strategy to unify all architectural, structural, and MEP aspects under a single data-rich model. This enabled real-time collaboration, error mitigation, and predictive structural performance analysis—streamlining execution from blueprint to build.

Implementation Process

1. BIM-Driven Structural Coordination

Built a high-resolution 3D BIM model integrating all architectural, structural, and MEP layers.
Utilized Autodesk Revit and Navisworks to simulate real-time scenarios and identify design conflicts before they escalated.
Enabled cloud-based collaboration, allowing remote stakeholders (architects, contractors, engineers) to access and update the model concurrently.

2. Advanced Structural Load & Stability Analysis

Performed wind tunnel simulations and earthquake load studies using STAAD.Pro and ETABS to validate the design for long-term structural resilience.
Designed an optimized load path system, repositioning columns and slabs to distribute forces efficiently across floors.

3. Cost-Effective Material Optimization

Suggested a switch from conventional RCC to high-strength reinforced concrete and lightweight steel framing, reducing dead loads.
Adjusted slab spans and column spacing to use 20% less structural material without compromising strength or safety.

4. Seismic & Regulatory Compliance

Ensured compliance with NBC 2016 guidelines, IS 456:2000, and IS 1893 for seismic design.
Conducted safety audits and collaborated with certified structural reviewers for third-party validation.

5. Contractor Communication & On-Site Coordination

Delivered fabrication-ready shop drawings and detailed GFC (Good for Construction) blueprints.
Assigned an on-site structural coordinator to supervise foundation casting, rebar placement, and beam-slab execution, ensuring fidelity to digital models.

Results Achieved

100% Structural & MEP Integration – All design conflicts were resolved pre-construction using clash detection and BIM coordination.
20% Material Cost Reduction – Efficient load distribution and optimized steel/concrete use saved ₹25 lakhs in material expenses.
Seismic Resilience Verified – The final structure met Zone V earthquake and high-wind resistance standards.
Faster Completion by 15% – Eliminated the need for design revisions during construction, reducing the build time significantly.
Improved Safety & Structural Longevity – Designed with reinforced concrete grades and durability-focused materials, ensuring a 50+ year lifecycle with minimal maintenance.

Conclusion & Key Takeaways

Structural design coordination is no longer optional—it’s a core necessity for modern commercial architecture. The success of this high-rise project by Sigma Solutions reinforces how BIM-based coordination, clash detection, and load optimization can dramatically improve construction outcomes.

By bridging the gap between design and execution, Sigma Solutions empowered stakeholders to build a high-rise that is safe, compliant, and built to last—without exceeding the budget or timeline.
